W samochodach marki BMW czasami pojawiają się kody błędów DTC informujące o usterkach które faktycznie nie istnieją. W wiekszości przypdków pomaga aktualizacja oprogramowania sterownika silnika.

• 2712 DMTL Solenoid Valve Activation
• 2713 Lambda Sensors Pre Cat Swapped
• 2714 Lambda Sensor Heater Post Cat Bank 2
• 2715 Lambda Sensor Heater Pre Cat Bank 2
• 2716 Lambda Sensor Heater Post Cat Bank 1
• 2717 Lambda Sensor Heater Post Cat Bank 2
• 2718 Crankshaft Sensor Reference
• 2719 Crankshaft Sensor Period
• 271A Lambda Sensor Pre Cat Bank 1- Signal
• 271C Lambda Sensor Post Cat Bank 1- Signal
• 271D Lambda Sensor Heater Pre Cat Bank 1
• 271E Lambda Sensor Heater Post Cat Bank 1
• 271F Lambda Sensor Timing Period
• 2720 Lambda Sensor Timing Switching Time
• 2721 Lambda Sensor Timing Post Cat Bank 1
• 2722 Lambda Sensor Pre Cat Bank 2- Signal
• 2724 Lambda Sensor Post Cat Bank 2- Signal
• 2725 Lambda Sensor Timing Bank 2- Period
• 2726 Lambda Sensor Timing Bank 2- Switching Time
• 2727 Lambda Sensor Timing Post Cat Bank 2
• 272A Multiplicative Adaptation Bank 1- Control Limit Reached
• 272B Multiplicative Adaptation Bank 2- Control Limit Reached
• 272C Additive Adaptation Bank 1- Control Limit Reached
• 272D Additive Adaptation Bank 2- Control Limit Reached
• 2731 Inlet Camshaft Control
• 2734 Throttle Valve Potentiometer 1- Signal Implausible to Mass Air Flow Sensor
• 2735 Throttle Valve Potentiometer 2- Signal Implausible to Mass Air Flow Sensor
• 2737 EWS 3.3 Anti Tampering Protection
• 2738 Catalytic Converter Efficiency Bank 1
• 2739 Catalytic Converter Efficiency Bank 1
• 273A Catalytic Converter Efficiency Bank 2
• 273D Catalytic Converter Efficiency Bank 2
• 2740 Pedal Position Sensor 1- Voltage Supply
• 2741 Pedal Position Sensor 2- Voltage Supply
• 2742 Misfire Detection Cyl 1
• 2743 Misfire Detection Cyl 3 (4cyl) or 5 (6 cyl)
• 2744 Misfire Detection Cyl 4 (4cyl) or 3 (6 cyl)
• 2745 Misfire Detection Cyl 2 (4cyl) or 6 (6 cyl)
• 2746 Misfire Detection Cyl 2
• 2747 Misfire Detection Cyl 4
• 274E Misfire Detection All Cyls
• 2750 Throttle Position Controller- Jammed Briefly
• 2751 Throttle Position Controller- Jammed Permanently
• 2752 Throttle Position Controller- Jamming
• 2753 Ignition Coil Cyl 1
• 2754 Ignition Coil Cyl 3 (4cyl) or 5 (6 cyl)
• 2755 Ignition Coil Cyl 4 (4cyl) or 3 (6 cyl)
• 2756 Ignition Coil Cyl 2 (4cyl) or 6 (6 cyl)
• 2757 Ignition Coil Cyl 2
• 2758 Ignition Coil Cyl 4
• 2760 Aux Air System Bank 1
• 2761 Aux Air System Bank 2
• 2764 Aux Air Pump Relay
• 2765 Solenoid Valve- Aux Air- Activation
• 2766 Inlet Camshaft Sensor- Signal Duration
• 2767 Exhaust Camshaft Sensor- Signal Duration
• 2768 Inlet Camshaft Sensor- Phase Position
• 2769 Throttle Actuator Spring Test
• 276C Exhaust Camshaft Sensor- Phase Position
• 276D Tank Venting System
• 2770 Aux Air Mass Air Flow Sensor
• 2772 Tank Vent Valve Output Stage
• 2774 CAN Message- Engine Shutdown Time
• 2775 Engine Torque Monitoring Level 2
• 2776 Multifunction Steering Wheel Interface
• 2777 DME Self Test: Monitoring AD Converter
• 2778 Clutch Switch
• 2779 DME Self Test RAM
• 277A Brake Light Switch
• 277B DME Self Test ROM
• 277C DME Self Test RESET
• 277D Battery Voltage
• 277E Engine Torque Monitoring Level 1
• 277F Crankshift Sensor Speed
• 2780 Crankshift Sensor Reference
• 2781 Camshaft Sensor Intake
• 2782 Camshaft Sensor Exhaust
• 2783 Mass Air Flow Sensor
• 2786 Throttle Valve Potentiometer 1
• 2787 Throttle Valve Potentiometer 2
• 2788 Vehicle Speed
• 2789 Rough Running Detection
• 278A Ambient Temperature Sensor
• 278B Engine Coolant Temperature Sensor
• 278C Intake Air Temperature Sensor
• 278D Radiator Outlet Temperature Sensor
• 278E Differertial Pressure Sensor- Intake Manifold
• 278F Alternator – Under-Excitation
• 2790 Radiator Outlet Temperature
• 2791 Throttle Adaptation Required
• 2792 Throttle Actuator Position Monitoring
• 2793 Throttle Actuator Control Range
• 2794 Throttle Actuator Activation
• 2795 Throttle Actuator Spring Test
• 2796 Throttle Actuator Test Lower Stop
• 2797 Throttle Actuator Booster Adjustment
• 2798 Throttle Actuator Emergency Operating Point
• 2799 Throttle Actuator Adaptation Aborted Environmental Conditions
• 279A Throttle Actuator Relearn Abort
• 279B Map Cooling Thermostat Mechanism
• 279C Map Cooling Thermostat Output Stage
• 279D Electric Fan Output Stage
• 279E Exhaust Flap Output Stage
• 27A0 E-Box Fan Activation
• 27A1 Throttle- Starting Test
• 27A4 Interface DME-EWS
• 27A5 Throttle Adaptation
• 27A6 Fuel Injector Cyl 1
• 27A7 Fuel Injector Cyl 3 (4cyl or 5 (6cyl)
• 27A8 Fuel Injector Cyl 4 (4cyl or 3 (6cyl)
• 27A9 Fuel Injector Cyl 2 (4cyl or 6 (6cyl)
• 27AA Fuel Injector Cyl 2
• 27AB Fuel Injector Cyl 4
• 27B2 Brake Light Switch- Signal
• 27B3 Throttle – Mass Air Flow Adjustment Plausibility
• 27B4 Ambient Pressure Sensor
• 27B5 Inlet Camshaft Control Output Stage
• 27B7 Fuel Pump Relay Output Stage
• 27B8 Differential Pressure Sensor Intake Manifold Plausibility
• 27B9 Lambda Sensor Pre Cat Bank 1- Voltage Excursion
• 27BA Lambda Sensor Pre Cat Bank 2- Voltage Excursion
• 27BB Exhaust Camshaft Control
• 27BD Exhaust Camshaft Control Output Stage
• 27C1 All Camshaft Sensors Failed
• 27C2 AirCon Compressor Control Output Stage
• 27C3 Oil Level Sensor
• 27C4 Main Relay
• 27C5 Brake Light Test Switch- Signal
• 27C7 Main Relay Switching Time
• 27CA DMTL Pump Motor- Activation
• 27CC DMTL Leakage
• 27CD DMTL Module Failure
• 27CE Load Monitoring
• 27CF Firing Cyl 1
• 27D0 Firing Cyl 5
• 27D1 Firing Cyl 3
• 27D2 Firing Cyl 6
• 27D3 Firing Cyl 2
• 27D4 Firing Cyl 4
• 27D6 Idle Speed Control Valve- Activation – Position Closed
• 27D7 Idle Speed Control Valve- Activation – Position Open
• 27D9 DMTL Heater- Activation
• 27DA Alternator BSD Fault
• 27DB Accelerator and Brake Pedals- Signal
• 27DC EWS 3.3 Random Code Storage
• 27DD Engine Coolant Temp Sensor- Gradient
• 27DE Engine Coolant Temp Sensor- Signal
• 27DF Engine Coolant Temp Sensor- Signal Constant
• 27E0 Crank Position Sensor- Segment Timing
• 27E1 Pedal Travel Sensor Monitoring
• 27E2 Knock Sensor 1
• 27E3 Knock Sensor 2
• 27E6 Knock Control Zero Test
• 27E7 Knock Control Offset
• 27E8 Knock Control Test Pulse
• 27EB CAN message EGS
• 27EC CAN message EGS
• 27ED CAN message ASC/DSC
• 27EE CAN message Instrument Cluster
• 27F2 Tank Fill Level
• 27F3 CAN message Valvetronic Control Unit
• 27F7 Pedal Travel Sensor Potentiometer 1
• 27F8 Pedal Travel Sensor Potentiometer 2
• 27FB Radiator Shutter
• 2800 CAN message Instrument Cluster
• 2804 Cruise Control Request
• 2805 Cruise Control Switch Signal
• 2806 Cruise Control Data Transmission
• 2807 Throttle Position Sensor Implausible- 1 vs. 2
• 2808 Throttle Position Sensor Implausible- Ratio
• 2809 CAN message Instrument Cluster
• 280B CAN message DSC
• 280C CAN message DSC
• 280D CAN message Steering Angle Sensor
• 280E CAN message SMG
• 280F CAN message DSC
• 2811 Local CAN Communication Error
• 2812 Oil Temperature
• 2813 DME Monitoring Group A
• 2814 DME Monitoring Group B
• 2815 DME Monitoring Group C
• 2816 DME Monitoring Speed Sensor or ECU Fault
• 281A CAN No Message TxU
• 281C BSD Interface Signal
• 281D BSD Signal
• 281E DISA Intake System Output Stage
• 2823 Lambda Sensor Heater Pre Cat Bank 1
• 2824 Lambda Sensor Heater Pre Cat Bank 2
• 2825 Lambda Sensor Timing Bank 1
• 2826 Lambda Sensor Timing Bank 2
• 282F CAN Communication Fault
• 2830 DME Self Test Checksum
• 2831 DME Self Test Processor Monitoring
• 283A Oil Condition Sensor
• 283D PT-CAN Communication Error
• 283E Variable Valve Gear Output Stage Enable Line
• 283F Oil Pressure Switch Implausibility
• 2850 Variable Valve Gear Guide Sensor
• 2852 Variable Valve Gear Reference Sensor
• 2854 Variable Valve Gear Plausibility Sensor
• 2856 Variable Valve Gear Voltage Supply
• 2858 Variable Valve Gear Adaptation Function
• 285A Variable Valve Gear Servomotor Monitoring
• 285C Variable Valve Gear CAN Communication
• 285E Variable Valve Gear Control Unit Internal Fault
• 2860 Variable Valve Gear Servomotor Output Stage
• 2862 Variable Valve Gear Voltage Supply Power Output Stage
• 2865 Variable Valve Gear Torque Limitation- Limp Mode
• 2866 Variable Valve Gear Adaptation Needed
• 2867 Variable Valve Gear Overload
• 286A DME Self Test- Knock Sensor Module
• 286B DME Self Test- Multiple Output Module
• 2882 Fuel Trim Bank 1
• 2883 Fuel Trim Bank 2
• 2892 Misfiring
• 2893 Control Module Temperature
• 2894 Control Module Fault
• 2895 Crankshaft Sensor- Signal
• 2896 Inlet Camshaft Sensor- Signal
• 2897 Exhaust Camshaft Sensor- Signal
• 2898 Lambda Sensor Post Cat- Bank 1 Signal
• 2899 Lambda Sensor Post Cat- Bank 2 Signal
• 289A Lambda Sensor Heater Pre Cat- Bank 1 Function
• 289B Lambda Sensor Heater Pre Cat- Bank 2 Function
• 289C Lambda Sensor Heater Post Cat- Bank 1 Function
• 289D Lambda Sensor Heater Post Cat- Bank 2 Function
• 289E Lambda Sensor Pre Cat Bank 1
• 289F Lambda Sensor Pre Cat Bank 2
• 28A1 Cruise Control -Monitoring
• 28A2 Air Flow -Monitoring
• 28A4 Engine Speed -Monitoring
• 28A5 Pedal Position Sensor -Monitoring
• 28AA Idle Control -Monitoring
• 28AB External Torque Request -Monitoring
• 28AC Specified Torque -Monitoring
• 28AD Actual Torque -Monitoring
• 28B1 Speed Limitation -Monitoring
• 28B2 Speed Limitation -Reset
• 28B3 Throttle -Continuous Adaptation
• 28B4 Button -Driving Dynamics Control
• 28B5 Sound Flap -Signal
• 28B6 Inlet Camshaft -Mechanical
• 28B8 Exhaust Camshaft -Mechanical
• 28BA Inlet Camshaft -Stiff
• 28BC Exhaust Camshaft -Stiff
• 28BD Inlet Camshaft Sensor -Locking
• 28BE Exhaust Camshaft Sensor -Locking
• 28C1 Lambda Sensor Pre Cat Bank 1
• 28C2 Lambda Sensor Pre Cat Bank 2
• 28C3 Lambda Sensor Heater Pre Cat Bank 1 Function
• 28C4 Lambda Sensor Heater Pre Cat Bank 2 Function
• 28C5 Lambda Sensor Post Cat Bank 1 System Check
• 28C6 Lambda Sensor Post Cat Bank 2 System Check
• 28CA Ozone Conversion- Too Low
• 28CB Ozone Sensor 2
• 28CC Ozone Sensor 1
• 28CF Fuel Pump- Emergency Shutoff
• 28D0 Fuel Pump- Monitoring
• 28D6 Process Error- Coding
• 28D7 Alternator Communication
• 28D8 RAM Backup
• 28DB Variable Valve Gear Minimum Lift Adaptation Exceeded
• 28DD Air Mass System
• 28E6 Evaluation Module Lambda Sensor Bank 1 On-board Diagnosis
• 28E7 Evaluation Module Lambda Sensor Bank 2 On-board Diagnosis
• 28E8 Lambda Sensor Bank 1 Trim Control
• 28E9 Lambda Sensor Bank 2 Trim Control
• 28EA Lambda Sensor Post Cat Bank 1 Signal
• 28EB Lambda Sensor Post Cat Bank 2 Signal
• 28EC Lambda Sensor Post Cat Bank 1 Signal at Full Load
• 28ED Lambda Sensor Post Cat Bank 2 Signal at Full Load
• 28F0 Lambda Sensor Post Cat Bank 1 System Check
• 28F1 Lambda Sensor Post Cat Bank 2 System Check
• 28F2 Lambda Sensor Bank 1 Trim Control
• 28F3 Lambda Sensor Bank 2 Trim Control
• 28F4 Lambda Sensor Pre Cat Bank 1 Cold Test
• 28F5 Lambda Sensor Pre Cat Bank 2 Cold Test
• 28F6 Lambda Sensor Post Cat Bank 1 Cold Test
• 28F7 Lambda Sensor Post Cat Bank 2 Cold Test
• 28F9 Rough Running- Segment Time Measurement
• 28FA CAN Torque for Switching Phase
• 28FB Active Cruise Control (ACC)
• 28FF DME Self Test
• 2900 DME Self Test
• 2960 Lambda Sensor Pre Cat Bank 1
• 2961 Lambda Sensor Pre Cat Bank 2
• 2962 Lambda Sensor Pre Cat Bank 1 Dynamics
• 2963 Lambda Sensor Pre Cat Bank 2 Dynamics
• 2964 Lambda Sensor Pre Cat Bank 1 Ceramic Temperature
• 2965 Lambda Sensor Pre Cat Bank 2 Ceramic Temperature
• 2966 Lambda Sensor Pre Cat Bank 1 Signal
• 2967 Lambda Sensor Pre Cat Bank 2 Signal
• 296A Lambda Sensors Pre Cat Swapped
• 296B Lambda Sensors Post Cat Swapped
• 2972 Jet Pump for Brake Servo
• 2973 Lambda Sensor Pre Cat Bank 1 Lines
• 2974 Lambda Sensor Pre Cat Bank 2 Lines
• 2986 Lambda Sensor Pre Cat Bank 1 System Check
• 2987 Lambda Sensor Pre Cat Bank 2 System Check
• 2988 Lambda Sensor Pre Cat Bank 1 System Check
• 2989 Lambda Sensor Pre Cat Bank 2 System Check
• 299A CAN Fault Management EGS
• 299B Battery Sensor
• 299C Battery Sensor
• 299D Battery Sensor
• 299E Lambda Sensor Post Cat Bank 1 Signal
• 299F Lambda Sensor Post Cat Bank 1 Signal
• 29A0 Lambda Sensor Post Cat Bank 2 Signal
• 29A1 Lambda Sensor Post Cat Bank 2 Signal
• 29A2 Lambda Sensor Pre Cat Bank 2 Signal
• 29A3 Lambda Sensor Pre Cat Bank 2 Signal
• 29A4 Lambda Sensor Heater Pre Cat Bank 1 Activation
• 29A5 Lambda Sensor Heater Pre Cat Bank 2 Activation
• 29A6 Lambda Sensor Pre Cat Bank 1 Signal
• 29A7 Lambda Sensor Pre Cat Bank 1 Signal
• 29A8 Power Management Vehicle Electrical System
• 29A9 Power Management Battery
• 29AB Torque Request via CAN
• 29AE Tank Cap
• 29B5 Aux Air System
• 29B6 Cylinder Cutout
• 29CC Misfire Several Cylinders
• 29CD Misfire Cyl 1
• 29CE Misfire Cyl 2
• 29CF Misfire Cyl 3
• 29D0 Misfire Cyl 4
• 29DD Rough Running Detection
• 29E5 Mixture Adaptation 1 Air Density Upper Speed Range
• 29E6 Mixture Adaptation 2 Air Density Upper Speed Range
• 29E7 Mixture Adaptation 1 Air Leak
• 29E8 Mixture Adaptation 2 Air Leak
• 29ED Mixture Adaptation 1 Air Density Lower Speed Range
• 29EE Mixture Adaptation 2 Air Density Lower Speed Range
• 29F4 Catalytic Converter Efficiency 1
• 29FE Aux Air System
• 29FF Aux Air System
• 2A03 Aux Air Pump Relay
• 2A19 Tank Venting Valve
• 2A59 Valvetronic Eccentric Shaft Sensor 1
• 2A5B Valvetronic Eccentric Shaft Sensor 1
• 2A5D Valvetronic Eccentric Shaft Sensor 1
• 2A5F Valvetronic Eccentric Shaft Sensor 1
• 2A61 Valvetronic Adaptation 1
• 2A63 Valvetronic Servomotor 1
• 2A67 Valvetronic Internal Fault
• 2A69 Valvetronic Voltage Supply Servomotor 1
• 2A6B Valvetronic Power Limitation Servomotor
• 2A6C Valvetronic Adaptation
• 2A6D Valvetronic Electrical Overload Protection 1
• 2A6F Valvetronic Minimum Lift Exceeded
• 2A70 Valvetronic Servomotor
• 2A71 Valvetronic Relief Relay
• 2A80 Inlet VANOS Activation 1
• 2A83 Inlet VANOS 1
• 2A85 Exhaust VANOS Activation 1
• 2A88 Exhaust VANOS 1
• 2B5C Crankshaft Sensor
• 2B5D Crankshaft Sensor
• 2B62 Camshaft Sensor 1 Inlet
• 2B63 Camshaft Sensor 2 Exhaust
• 2B66 Camshaft Sensor
• 2B70 Variable Intake System
• 2B7F Idle Speed Control
• 2B80 Idle Speed Control
• 2B8A Control Module- Internal Fault Knock Control
• 2B8B Control Module- Internal Fault Knock Control
• 2B8C Control Module- Internal Fault Knock Control
• 2B98 Control Module- Internal Fault RAM
• 2B99 Control Module- Internal Fault RAM
• 2B9A Control Module- Internal Fault RAM
• 2B9B Control Module- Internal Fault ROM
• 2B9C Control Module- Internal Fault Reset
• 2BA7 Engine Torque too High
• 2C24 Lambda Sensors Pre Cat Swapped
• 2C45 Lambda Sensor Pre Cat 1
• 2C46 Lambda Sensor Pre Cat 2
• 2C6A Lambda Sensor Post Cat Swapped
• 2C6D Lambda Sensor Post Cat 1 Timing
• 2C6E Lambda Sensor Post Cat 2 Timing
• 2C6F Lambda Sensor Post Cat 1
• 2C70 Lambda Sensor Post Cat 2
• 2C71 Lambda Sensor Post Cat 1
• 2C72 Lambda Sensor Post Cat 2
• 2C9C Lambda Sensor Heater Pre Cat 1
• 2C9D Lambda Sensor Heater Pre Cat 2
• 2CA0 Lambda Sensor Heater Pre Cat 1
• 2CA1 Lambda Sensor Heater Pre Cat 2
• 2CA2 Lambda Sensor Heater Pre Cat 1
• 2CA3 Lambda Sensor Heater Pre Cat 2
• 2CA8 Lambda Sensor Heater Post Cat 1
• 2CA9 Lambda Sensor Heater Post Cat 2
• 2CEF Throttle Valve Actuator
• 2CF0 Throttle Valve Actuator
• 2CF1 Throttle Valve Actuator
• 2CF8 Throttle Valve Potentiometer
• 2CF9 Throttle Valve Potentiometer 1
• 2CFA Throttle Valve Potentiometer 2
• 2CFF Throttle Valve Actuator
• 2D00 Throttle Valve Actuator
• 2D01 Throttle Valve Actuator
• 2D02 Throttle Valve Actuator
• 2D03 Throttle Valve Actuator
• 2D04 Throttle Valve Actuator
• 2D05 Throttle Valve Actuator
• 2D08 Throttle Actuator
• 2D0F Mass Air Flow Sensor Signal
• 2D19 Accelerator Pedal Module
• 2D1A Accelerator Pedal Module
• 2D1B Accelerator Pedal Module Signal 1
• 2D1C Accelerator Pedal Module Signal 2
• 2D28 Intake Manifold Pressure Sensor Signal
• 2D29 Intake Manifold Pressure Sensor Plausibility
• 2D6E Control Module Internal Fault Torque Monitoring
• 2D6F Load Sensor Monitoring
• 2D70 Control Module Internal Fault
• 2D71 Control Module Internal Fault
• 2D72 Control Module Internal Fault
• 2D73 Fuel Pressure Sensor
• 2D74 Fuel Pressure Sensor
• 2D75 Crankshaft Sensor
• 2D76 Accelerator Pedal Module
• 2E24 Ignition Coil Cyl 1
• 2E25 Ignition Coil Cyl 2
• 2E26 Ignition Coil Cyl 3
• 2E27 Ignition Coil Cyl 4
• 2E30 Fuel Injector Cyl 1
• 2E31 Fuel Injector Cyl 2
• 2E32 Fuel Injector Cyl 3
• 2E33 Fuel Injector Cyl 4
• 2E68 Knock Sensor Signal 1
• 2E69 Knock Sensor Signal 2
• 2E95 Generator
• 2E97 Generator
• 2EE0 Engine Coolant Temperature Sensor Signal
• 2EEA Radiator Outlet Temperature Sensor Signal
• 2EF4 Map Thermostat Mechanism Jammed
• 2EF5 Map Thermostat Activation
• 2EFE Electric fan
• 2F08 Intake Air Temperature Sensor Signal
• 2F12 AirCon Compressor Relay
• 2F17 Engine Oil Temperature too High
• 2F44 EWS Intervention
• 2F45 EWS Data Line
• 2F46 EWS Calibration
• 2F4E Road Speed Signal
• 2F62 Brake Light Switch
• 2F67 Clutch Switch
• 2F76 Control Module Internal Fault Ambient Pressure Sensor
• 2F85 Control module Internal fault Internal Temperature Sensor
• 2F8A Power Supply
• 2F94 Fuel Pump Relay Activation
• 2F99 External Temperature Sensor Plausibility
• 2F9E Oil Level Sensor
• 2FA3 Coding Error

• DDE 4 and DDE 4.1

  Hexadecimal

• 0100 Air Flow Sensor HFM
• 0105 Atmospheric Pressure Sensor
• 0110 Intake Air Temperature Sensor
• 0115 Coolant Temperature Sensor
• 0120 Pedal Position Sensor 1
• 0190 Rail Pressure Sensor
• 0200 Injector Cylinder 1
• 0201 Injector Cylinder 5
• 0202 Injector Cylinder 3
• 0203 Injector Cylinder 6
• 0204 Injector Cylinder 2
• 0205 Injector Cylinder 4
• 0220 Pedal Position Sensor 2
• 0235 Boost Pressure Sensor
• 0335 Crankshaft RPM
• 03E6 Exhaust Gas Recirculation Regulation
• 0400 Exhaust Gas Recirculation
• 0404 Exhaust Gas Recirculation 2
• 0480 Electric ECU Fan
• 0500 Vehicle Speed Sensor Signal
• 0560 Internal Reference Voltage
• 0600 DDE Error CAN Controller
• 0605 DDE Error
• 1190 Rail Pressure Regulation
• 1195 Rail Pressure Sensor
• 1250 Delivery Pump Relay
• 1255 Delivery Pump Pressure Sensor
• 1260 Delivery Pump Control System
• 1470 Boost Pressure Regulation
• 1612 DME Incorrectly Coded
• 1613 MAP Control
• 1640 DDE Error EEPROM or Coding
• 1A04 Aux. Heater
• 1DF0 Engine Stall
• 1DF5 EWS – Timeout
• 1E00 CAN Communication to ASC
• 1E05 Vehicle Speed Sensor
• 1E25 RPM Regulation
• 1E30 Boost Pressure Regulation or Actuator
• 1E31 Boost Pressure Regulation
• 1E35 Error During Switch off
• 1E40 A/D Converter
• 1E45 Capacitor Voltage 1 for Cyl 1, 2, 3
• 1E50 Capacitor Voltage 2 for Cyl 4, 5, 6
• 1E55 RPM Control
• 1E60 Power Supply Pedal Sensor 1
• 1430 Boost Pressure or Actuator
• 2800 DDE Power Supply
• 3000 Brake Light or Brake Light Test Switch
• 3005 Voltage Supply KL15
• 3505 Glow Plug System
• 3506 Glow Plug System 2
• 3510 DDE Main Relay
• 3515 AirCon Power Output
• 3520 Engine Boost Actuation
• 3565 High Pressure Pump
• 3580 High Pressure Pump Shut Off Valve
• 3596 Brake Light Switch
• 3600 Atmospheric Pressure Sensor
• 3605 Air Flow Meter HFM 1 or 2
• 3610 Exhaust Gas Recirculation System
• 3615 Exhaust Gas Recirculation System -Regulation
• 3620 Air Flow Meter HFM Signal

• DDE 5, DDE 6, DDE 6.2 and DDE 6.3

  Hexadecimal

• 3E90 Crankshaft RPM – No Signal
• 3E91 Crankshaft RPM – Wrong Signal
• 3E95 Intake air Temperature Sensor
• 3EA0 Crankshaft Position Sensor
• 3EA1 Crankshaft Position Sensor
• 3EA5 Intake air Temperature Sensor
• 3EA6 Intake air Temperature Sensor
• 3EB0 RPM Calculation
• 3EB5 Air flow Sensor 2
• 3EB6 Air flow Sensor 2
• 3EC0 Camshaft Sensor – No Signal
• 3EC1 Camshaft Sensor – Wrong Signal
• 3EC7 Camshaft Sensor
• 3ED0 Camshaft Sensor – No Signal
• 3ED1 Camshaft Sensor – Wrong Signal
• 3ED5 Air Flow Sensor 2
• 3ED6 Air Flow Sensor 2
• 3EDC Variant Coding
• 3EDD Variant Coding
• 3EE0 Coolant Temperature Sensor -Short Circuit to B+ or Open
• 3EE1 Coolant Temperature Sensor -Short Circuit to B-
• 3EE2 Coolant Temperature Sensor
• 3EE3 Coolant Temperature Sensor
• 3EE5 Air Mass Flow Sensor 2
• 3EE6 Air Mass Flow Sensor 2
• 3EE7 Air Mass Flow Sensor 2
• 3EED Power Management Closed Circuit Current
• 3EF3 Coolant Temperature Sensor not Plausible
• 3EF5 Intake Air Temperature Sensor 2 (HFM Reference Signal)
• 3EF6 Intake Air Temperature Sensor 2 (HFM Reference Signal)
• 3EF7 Intake Air Temperature Sensor 2 (HFM Reference Signal)
• 3EFB Thermal Oil Level Sensor
• 3EFC Thermal Oil Level Sensor
• 3EFD Thermal Oil Level Sensor
• 3F00 Boost Pressure Sensor -Short circuit to B+
• 3F01 Boost Pressure Sensor -Short circuit to B- or Open
• 3F02 Boost Pressure Sensor
• 3F03 Boost Pressure Sensor -Plausibility
• 3F05 MIL OFF
• 3F10 Pedal Position Sensor 1
• 3F11 Pedal Position Sensor 1 – Short circuit to B-
• 3F13 Pedal Position Sensor 1 – Potentiometer Plausibility
• 3F15 MIL ON
• 3F20 Pedal Position Sensor 2
• 3F21 Pedal Position Sensor 2 – Short Circuit to B-
• 3F23 Pedal Position Sensor 2 – Potentiometer Plausibility
• 3F25 Input Air Flow Control
• 3F30 Rail Pressure Sensor – Short Circuit to B+
• 3F31 Rail Pressure Sensor – Short Circuit to B-
• 3F35 Input Air Flow Control at Idle Speed
• 3F40 Rail Pressure Sensor – Max for Compensation
• 3F41 Rail Pressure Sensor – Min for Compensation
• 3F47 Brake Light or Brake Light Test Switch
• 3F48 Brake Light or Brake Light Test Switch
• 3F50 Vehicle Speed Signal – Too High
• 3F51 Vehicle Speed Signal
• 3F52 Vehicle Speed Signal
• 3F53 Vehicle Speed Signal
• 3F60 Pedal Position Sensor Ref. VSS
• 3F62 Vehicle Speed Signal from CAN
• 3F67 Filling Pressure Modulator 2
• 3F70 Intake Air Temperature Sensor
• 3F71 Intake Air Temperature Sensor
• 3F72 Intake Air Temperature Sensor
• 3F77 Boost Pressure Modulator 1
• 3F82 Ambient Temp Sensor
• 3F87 Boost Pressure Modulator 2
• 3F97 Boost Pressure Modulator 1
• 3FB0 Air Flow Meter – Signal too High or Short circuit to B+
• 3FB1 Air Flow Meter – Signal too Low or Short circuit to B-
• 3FB5 Control Master/Slave
• 3FB6 Control Master/Slave
• 3FB7 Control Unit – Internal Master
• 3FC0 Air Flow Meter – Deviation too High at Idle Speed
• 3FD0 Air Flow Meter – Deviation too High
• 3FE0 Air Flow Meter
• 3FE1 Air Flow Meter
• 3FF0 Air Flow Meter
• 3FF1 Air Flow Meter
• 4000 Fuel Temperature Sensor
• 4001 Fuel Temperature Sensor
• 4010 Exhaust Gas Pressure Sensor -Short Circuit to B+
• 4011 Exhaust Gas Pressure Sensor -Short Circuit to B-
• 4020 EGT -Short Circuit to B+
• 4021 EGT -Short Circuit to B-
• 4030 EGT Before Cat -Short Circuit to B+
• 4031 EGT Before Cat -Short Circuit to B-
• 4032 Exhaust Gas Pressure Sensor
• 4060 Atmospheric Pressure Sensor DDE-Short Circuit to B+
• 4061 Atmospheric Pressure Sensor DDE-Short Circuit to B-
• 4062 Atmospheric Pressure Sensor DDE
• 4063 Atmospheric Pressure Sensor DDE-Plausibility Ref. Boost
• 4072 Automatic Gearbox Switch Signal
• 4080 Brake Light or Brake Light Test Switch
• 4082 Brake Light or Brake Light Test Switch
• 4083 Brake Light or Brake Light Test Switch
• 40A1 Alternator Signal
• 40E0 Alternator
• 4100 AirCon Power Output
• 4101 AirCon Power Output
• 4102 AirCon Power Output
• 4103 AirCon Power Output
• 4108 Control Master/Slave
• 410C Swirl Flap Actuactor
• 4117 Control Master/Slave
• 4118 Control Master/Slave
• 4120 DDE Main Relay is Switching too Late or too Early
• 4121 DDE Main Relay is Switching too Late or too Early
• 4125 Power Supply
• 4126 Power Supply
• 4130 Swirlflaps – Short Circuit to B+
• 4135 Power Supply
• 4136 Power Supply
• 4140 Swirlflap
• 4141 Swirlflaps – Short Circuit to B-
• 4145 Power Supply
• 4146 Power Supply
• 4152 Swirlflaps – Open Circuit
• 4153 Swirlflaps – Plausibility, Overtemp of Output Stage
• 4155 Exhaust Flap Actuator
• 4156 Exhaust Flap Actuator
• 4157 Exhaust Flap Actuator
• 4158 Exhaust Flap Actuator
• 4160 Raise Pressure Pump – Short Circuit to B+
• 4161 Raise Pressure Pump – Short Circuit to B-
• 4162 Raise Pressure Pump – Activation Interrupted
• 4163 Raise Pressure Pump – Plausibility, Overtemp of Output Stage
• 4165 DPF -Flow Resistance too High
• 4166 DPF -Flow Resistance too Low
• 4175 Exhaust Gas Temp Sensor before DPF
• 4180 Boost Pressure Actuator – Short Circuit to B+
• 4185 Exhaust Gas Temp Sensor before Cat
• 4186 Exhaust Gas Temp Sensor before Cat
• 4188 Exhaust Gas Temp Sensor before Cat
• 4190 Boost Pressure Actuator
• 4191 Boost Pressure Actuator – Short Circuit to B-
• 419A Atmospheric Pressure Sensor DDE
• 419B Atmospheric Pressure Sensor DDE
• 41A0 Boost Pressure Actuator
• 41A1 Boost Pressure Actuator – Adjustment
• 41A2 Boost Pressure Actuator – Open Circuit
• 41A3 Boost Pressure Actuator – Plausibility, Overtemp of Output Stage
• 41A6 Message CBS Reset
• 41A7 Message CBS Reset
• 41AA Boost Pressure Sensor
• 41AB Boost Pressure Sensor
• 41B0 Exhaust Gas Recirculation -Short Circuit to B+
• 41B5 Transmission Fluid Temperature Sensor
• 41BA Exhaust Backpressure Sensor
• 41BB Exhaust Backpressure Sensor
• 41C0 Activation -Fan
• 41C1 Activation -Fan- Short Circuit to B-
• 41C2 Activation -Fan- Activation Interrupted
• 41C3 Activation -Fan- Plausibility, Overtemp of Output Stage
• 41CD Exhaust Backpressure Sensor – Plausibility
• 41D0 Exhaust Gas Recirculation Regulation
• 41D1 Exhaust Gas Recirculation -Short Circuit to B-
• 41D5 Lambda Sensor Bias -Short Circuit to B+
• 41D6 Lambda Sensor Bias -Short Circuit to B-
• 41D7 Lambda Sensor Bias -Open Circuit
• 41E0 Exhaust Gas Recirculation Regulation
• 41E2 Exhaust Gas Recirculation – Open Circuit
• 41E3 Exhaust Gas Recirculation -Plausibility, Overtemp of Output Stage
• 41E5 Lambda Sensor -Short Circuit to B+
• 41E6 Lambda Sensor -Short Circuit to B-
• 41E7 Lambda Sensor -Open Circuit
• 41F0 Electric Ventilator – Short Circuit to B+
• 41F1 Electric Ventilator – Short Circuit to B-
• 41F2 Electric Ventilator – Activation Interrupted
• 41F3 Electric Ventilator – Plausibility, Overtemp of Output Stage
• 41F5 Lambda Sensor Virtual Earth -Short Circuit to B+
• 41F6 Lambda Sensor Virtual Earth -Short Circuit to B-
• 41F7 Lambda Sensor Virtual Earth -Open Circuit
• 4203 Glow Module Communication
• 4205 Lambda Sensor Heating -Short Circuit to B+
• 4206 Lambda Sensor Heating -Short Circuit to B-
• 4207 Lambda Sensor Heating
• 420B EGR in Regen Mode
• 4211 Glow Plug Cyl 1 – Short Circuit to B+
• 4212 Glow Plug Cyl 1 – Activation Interrupted
• 4213 Glow Plug Cyl 1 – Plausibility, Overtemp of Output Stage
• 4217 Lambda Sensor
• 4221 Glow Plug Cyl 2 – Short Circuit to B+
• 4222 Glow Plug Cyl 2 – Activation Interrupted
• 4223 Glow Plug Cyl 2 – Plausibility, Overtemp of Output Stage
• 4225 Lambda Sensor -Signal
• 4226 Lambda Sensor -Signal too Low
• 422A EGR in Regen Mode
• 4231 Glow Plug Cyl 3 – Short Circuit to B+
• 4232 Glow Plug Cyl 3 – Activation Interrupted
• 4233 Glow Plug Cyl 3 – Plausibility, Overtemp of Output Stage
• 4235 Control Unit Internal 21
• 4236 Control Unit Internal 21
• 4241 Glow Plug Cyl 4 – Short Circuit to B+
• 4242 Glow Plug Cyl 4 – Activation Interrupted
• 4243 Glow Plug Cyl 4 – Plausibility, Overtemp of Output Stage
• 4245 Control Unit Internal 22
• 4246 Control Unit Internal 22
• 4251 Glow Plug Cyl 5 – Short Circuit to B+
• 4252 Glow Plug Cyl 5 – Activation Interrupted
• 4253 Glow Plug Cyl 5 – Plausibility, Overtemp of Output Stage
• 4258 Control Unit Internal 23
• 425D Accelerator Pedal Potentiometer Plausibility
• 4261 Glow Plug Cyl 6 – Short Circuit to B+
• 4262 Glow Plug Cyl 6 – Activation Interrupted
• 4263 Glow Plug Cyl 6 – Plausibility, Overtemp of Output Stage
• 4267 Lambda Sensor Shunt Detection
• 4271 Glow Plug Cyl 7 – Short Circuit to B+
• 4272 Glow Plug Cyl 7 – Activation Interrupted
• 4273 Glow Plug Cyl 7 – Plausibility, Overtemp of Output Stage
• 4275 Lambda Sensor Heater
• 4276 Lambda Sensor Heater
• 4281 Glow Plug Cyl 8 – Short Circuit to B+
• 4282 Glow Plug Cyl 8 – Activation Interrupted
• 4283 Glow Plug Cyl 8 – Plausibility, Overtemp of Output Stage
• 4288 Lambda Sensor Heater
• 428B Boost Pressure Control of Large Turbo Control Deviation
• 4293 Control Unit Internal Error 16
• 4296 Lambda Sensor
• 4298 Lambda Sensor
• 429A Boost Pressure Control of Large Turbo Control Deviation
• 42B5 RPM Control
• 42C0 Oil Pressure Indicator Lamp – Short Circuit to B+
• 42C1 Oil Pressure Indicator Lamp – Short Circuit to B-
• 42C2 Oil Pressure Indicator Lamp – Activation interrupted
• 42C3 Oil Pressure Indicator Lamp – Plausibility, Overtemp of Output Stage
• 42D5 Injector Cylinder 7
• 42D6 Injector Cylinder 7
• 42D7 Injector Cylinder 7
• 42D8 Injector Cylinder 7
• 42E2 Changeover Rail Pressure Control
• 42F2 Changeover Rail Pressure Control
• 42F5 Injector Cylinder 8
• 42F6 Injector Cylinder 8
• 42F7 Injector Cylinder 8
• 42F8 Injector Cylinder 8
• 4302 Quantity Regulation Valve – Activation interrupted
• 4303 Quantity Regulation Valve – Plausibility, Overtemp of Output Stage
• 4310 Quantity Regulation Valve – Short Circuit to B+
• 4321 Quantity Regulation Valve – Short Circuit to B-
• 4332 Rail Pressure Regulation Valve – Activation Interrupted
• 4333 Rail Pressure Regulation Valve – Plausibility, Overtemp of Output Stage
• 4340 Rail Pressure Regulation Valve – Short Circuit to B+
• 4351 Rail Pressure Regulation Valve – Short Circuit to B-
• 4360 Rail Pressure Regulation Valve – Current Regulation
• 4361 Rail Pressure Regulation Valve – Current Regulation
• 4362 Rail Pressure Regulation Valve – Current Regulation
• 4373 Air Flow Mass not Plausible
• 4378 Rail Pressure Regulation Valve – Defect
• 4382 Rail Pressure Valve Position Test
• 4390 Boost Air Temperature Sensor – Short Circuit to B+
• 4391 Boost Air Temperature Sensor – Short Circuit to B-
• 4392 Boost Air Temperature Sensor
• 4397 Position Test Volume Adjust Valve
• 43A0 Start-block Relay
• 43A1 Start-block Relay
• 43A2 Start-block Relay
• 43A3 Start-block Relay
• 43C0 Throttle Valve Actuator -Short Circuit to B+
• 43D1 Throttle Valve Actuator -Short Circuit to B-
• 43E2 Throttle Valve Actuator -Open Circuit
• 43E3 Throttle Valve Actuator -Plausibility, Overtemp of Output Stage
• 43F0 Electrical Aux Heater – Short Circuit to B+
• 43F1 Electrical Aux Heater – Short Circuit to B-
• 43F2 Electrical Aux Heater – Activation Interrupted
• 43F3 Electrical Aux Heater – Plausibility, Overtemp of Output Stage
• 4403 Control Unit Internal Error 17
• 4410 Injector Cylinder 1- Activation
• 4411 Injector Cylinder 1- Activation
• 4412 Injector Cylinder 1- Activation
• 4413 Injector Cylinder 1- Activation
• 4417 Control Master/Slave
• 441C Injector Cylinder 1 – Earth Side Activation or Open Circuit
• 4420 Injector Cylinder 2- Activation
• 4421 Injector Cylinder 2- Activation
• 4422 Injector Cylinder 2- Activation
• 4423 Injector Cylinder 2- Activation
• 4428 Control Master/Slave
• 442C Injector Cylinder 2 – Earth Side Activation or Open Circuit
• 4430 Injector Cylinder 3- Activation
• 4431 Injector Cylinder 3- Activation
• 4432 Injector Cylinder 3- Activation
• 4433 Injector Cylinder 3- Activation
• 4438 Control Master/Slave
• 443C Injector Cylinder 3 – Earth Side Activation or Open Circuit
• 4440 Injector Cylinder 4- Activation
• 4441 Injector Cylinder 4- Activation
• 4442 Injector Cylinder 4- Activation
• 4443 Injector Cylinder 4- Activation
• 444C Injector Cylinder 4 – Earth Side Activation or Open Circuit
• 4450 Injector Cylinder 5- Activation
• 4451 Injector Cylinder 5- Activation
• 4452 Injector Cylinder 5- Activation
• 4453 Injector Cylinder 5- Activation
• 445C Injector Cylinder 5 – Earth Side Activation or Open Circuit
• 4460 Injector Cylinder 6- Activation
• 4461 Injector Cylinder 6- Activation
• 4462 Injector Cylinder 6- Activation
• 4463 Injector Cylinder 6- Activation
• 446C Injector Cylinder 6 – Earth Side Activation or Open Circuit
• 4473 Control Unit Internal Error 18
• 4480 Control Unit Internal Error 19
• 4491 Control Unit Internal Error 20
• 44A0 Injectors: Activation Cylinder. 1, 2, 3
• 44A1 Injectors: Activation Cylinder. 1, 2, 3
• 44A3 Injectors: Activation Cylinder. 1, 2, 3
• 44AC Injectors: Activation Cylinder. 1, 2, 3
• 44B0 Injectors: Activation Cylinder. 1, 2, 3
• 44B1 Injectors: Activation Cylinder. 4, 5, 6
• 44B3 Injectors: Activation Cylinder. 4, 5, 6
• 44BC Injectors: Activation Cylinder. 4, 5, 6
• 44C0 Number of Requested Injections Limited
• 44C1 Number of Requested Injections Limited
• 44C2 Number of Requested Injections Limited
• 44D0 Alternator
• 44D2 Alternator
• 44D3 Alternator
• 44E2 Alternator
• 44E3 Alternator
• 44F0 Rail Pressure not Plausible
• 4500 Exhaust Gas Recirculation- Deviation
• 4501 Exhaust Gas Recirculation- Negative Deviation or Air Mass too High
• 4506 Exhaust Gas Recirculation- Deviation
• 4507 Exhaust Gas Recirculation- Posative Deviation or Air Mass too Low
• 4512 Thermal Oil Level Sensor
• 4513 Thermal Oil Level Sensor
• 4521 Boost Pressure Actuator – Regulation Pressure too High
• 452A DPF System
• 4530 Boost Pressure Actuator – Regulation Pressure too Low
• 4536 Power Management
• 453B PT Can Bus
• 453C PT Can Bus
• 453D PT Can Bus
• 4541 Thermal Oil Level Sensor
• 454B Private CAN bus(master)
• 454C Private CAN bus(master)
• 454D Private CAN bus(master)
• 4550 Boost Pressure Modulation 2
• 4560 Rail Pressure Sensor – Plausibility -Pressure too Low
• 4570 Rail Pressure not Plausible
• 4580 Rail Pressure Sensor – Plausibility -Pressure too High
• 4587 Fuel Filter
• 4590 Rail Pressure not Plausible
• 45A0 Rail Pressure Sensor – Plausibility -Pressure too High
• 45A5 Boost Air Temp Sensor 2- Signal
• 45A6 Boost Air Temp Sensor 2- Signal
• 45C0 Rail Pressure not Plausible
• 45E3 Control Master/Slave
• 45F2 Control Master/Slave
• 45F3 Control Master/Slave
• 4600 Rail Pressure Sensor – Plausibility -Pressure too Low
• 4605 DPF System
• 4610 Rail Pressure not Plausible
• 4618 DPF -Plausibility -Pressure Reference
• 4620 Rail Pressure Sensor – Plausibility -Pressure too High
• 4628 DPF System
• 4630 Rail Pressure not Plausible
• 4640 Rail Pressure not Plausible
• 4645 EGR Controller
• 4650 Rail Pressure not Plausible
• 4656 Control Unit Internal 24
• 4660 Power Supply
• 4661 Power Supply
• 4665 DPF Bank 1
• 4666 DPF Bank 1
• 4667 DPF Bank 1
• 4670 Power Supply 1 – Short Circuit to B+
• 4671 Power Supply 1 – Short Circuit to B-
• 4677 Throttle Valve Actuator
• 4680 Power Supply 2 – Short Circuit to B+
• 4681 Power Supply 2 – Short Circuit to B-
• 4687 Throttle Valve Actuator
• 4690 Power Supply
• 4691 Power Supply
• 4697 Throttle Valve Actuator
• 46A0 Control Unit Internal Error 1
• 46A1 Control Unit Internal Error 1
• 46A2 Control Unit Internal Error 1
• 46A3 Control Unit Internal Error 1
• 46A7 Swirl Flap Actuator
• 46B0 Control Unit Internal Error 2
• 46B1 Control Unit Internal Error 2
• 46B2 Control Unit Internal Error 2
• 46B3 Control Unit Internal Error 2
• 46B7 Swirl Flap Actuator
• 46C0 Control Unit Internal Error 3
• 46C1 Control Unit Internal Error 3
• 46C2 Control Unit Internal Error 3
• 46C3 Control Unit Internal Error 3
• 46C7 Swirl Flap Actuator
• 46D0 Control Unit Internal Error 4
• 46D1 Control Unit Internal Error 4
• 46D2 Control Unit Internal Error 4
• 46D3 Control Unit Internal Error 4
• 46D5 Compressor Bypass Activation
• 46D6 Compressor Bypass Activation
• 46D7 Compressor Bypass Activation
• 46D8 Compressor Bypass Activation
• 46E0 Control Unit Internal Error 5
• 46E1 Control Unit Internal Error 5
• 46E2 Control Unit Internal Error 5
• 46E3 Control Unit Internal Error 5
• 46E5 Wastegate Valve Activation
• 46E6 Wastegate Valve Activation
• 46F0 Control Unit Internal Error 6
• 46F1 Control Unit Internal Error 6
• 46F2 Control Unit Internal Error 6
• 46F3 Control Unit Internal Error 6
• 4700 Control Unit Internal Error 7
• 4701 Control Unit Internal Error 7
• 4702 Control Unit Internal Error 7
• 4703 Control Unit Internal Error 7
• 4707 Wastegate Valve Activation
• 4708 Wastegate Valve Activation
• 4710 Control Unit Internal Error 8
• 4711 Control Unit Internal Error 8
• 4712 Control Unit Internal Error 8
• 4713 Control Unit Internal Error 8
• 4720 Control Unit Internal Error 9
• 4721 Control Unit Internal Error 9
• 4722 Control Unit Internal Error 9
• 4723 Control Unit Internal Error 9
• 4730 Quantity Regulation Current Regulation
• 4731 Quantity Regulation Current Regulation
• 4732 Quantity Regulation Current Regulation
• 4740 Control Unit Internal Error 11
• 4747 Injectors – Amplifier Adjustment(control unit internal)
• 4750 Control Unit Internal Error 12
• 4753 Control Unit Internal Error 12
• 475A Exhaust Backpressure Sensor- Bank 2
• 475B Exhaust Backpressure Sensor- Bank 2
• 4763 Control Unit Internal Error 13
• 4765 Injector Cyl 1 – Activation
• 4766 Injector Cyl 1 – Activation
• 4767 Injector Cyl 1 – Activation
• 4768 Injector Cyl 1 – Activation
• 476A Injector Cyl 4/5/6 Buffer Voltage Measurement(control unit internal)
• 476B Injector Cyl 4/5/6 Buffer Voltage Measurement(control unit internal)
• 4770 Control Unit Internal Error 14
• 4771 Control Unit Internal Error 14
• 4772 Control Unit Internal Error 14
• 4773 Control Unit Internal Error 14
• 477C Injectors Activation Duration(control unit internal)
• 4780 Control Unit Internal Error 15
• 4781 Control Unit Internal Error 15
• 4782 Control Unit Internal Error 15
• 4783 Control Unit Internal Error 15
• 4785 Injector Cyl 2 – Activation
• 4786 Injector Cyl 2 – Activation
• 4787 Injector Cyl 2 – Activation
• 4788 Injector Cyl 2 – Activation
• 478C Injector Activation Duration(control unit internal)
• 4792 Monitoring Master/Slave
• 4793 Monitoring Master/Slave
• 4795 Injector Cyl 3 – Activation
• 4796 Injector Cyl 3 – Activation
• 4797 Injector Cyl 3 – Activation
• 4798 Injector Cyl 3 – Activation
• 47A5 Injector Cyl 4 – Activation
• 47A6 Injector Cyl 4 – Activation
• 47A7 Injector Cyl 4 – Activation
• 47A8 Injector Cyl 4 – Activation
• 47AB Private CAN Bus(Slave)
• 47AC Private CAN Bus(Slave)
• 47AD Private CAN Bus(Slave)
• 47B5 Injector Cyl 5 – Activation
• 47B6 Injector Cyl 5 – Activation
• 47B7 Injector Cyl 5 – Activation
• 47B8 Injector Cyl 5 – Activation
• 47BB Power Train CAN Bus(Slave)
• 47BC Power Train CAN Bus(Slave)
• 47BD Power Train CAN Bus(Slave)
• 47C5 Injector Cyl 6 – Activation
• 47C6 Injector Cyl 6 – Activation
• 47C7 Injector Cyl 6 – Activation
• 47C8 Injector Cyl 6 – Activation
• 47D5 Injector Cyl 7 – Activation
• 47D6 Injector Cyl 7 – Activation
• 47D7 Injector Cyl 7 – Activation
• 47D8 Injector Cyl 7 – Activation
• 47E5 Injector Cyl 8 – Activation
• 47E6 Injector Cyl 8 – Activation
• 47E7 Injector Cyl 8 – Activation
• 47E8 Injector Cyl 8 – Activation
• 4803 Torque Control ACC
• 480A DPF -Bank 1
• 4810 Torque Control ACC
• 481A DPF -Bank 1
• 4830 Intake Air Temperature Sensor
• 4831 Intake Air Temperature Sensor
• 483D Throttle Actuator
• 4841 Exhaust Gas Recirculation Regulation 2
• 484A Accelerator Pedal Potentiometer -Signal
• 4850 Exhaust Gas Recirculation Regulation 2
• 4857 Swirl Flap Actuator
• 4863 Vehicle Speed Regulation
• 4867 Swirl Flap Actuator
• 486D Control Unit Software Fault
• 4877 Swirl Flap Actuator
• 487A Lambda Sensor Bank 2 – Bias Voltage
• 487B Lambda Sensor Bank 2 – Bias Voltage
• 487C Lambda Sensor Bank 2 – Bias Voltage
• 4887 Swirl Flap Actuator
• 488A Lambda Sensor Bank 2 – Pump Current
• 488B Lambda Sensor Bank 2 – Pump Current
• 488C Lambda Sensor Bank 2 – Pump Current
• 4896 Swirl Flap Actuator
• 489A Lambda Sensor Bank 2 – Virtual Ground
• 489B Lambda Sensor Bank 2 – Virtual Ground
• 489C Lambda Sensor Bank 2 – Virtual Ground
• 48A2 CAN Communication with ASC
• 48A3 CAN Communication with ASC
• 48B2 CAN Communication with ASC
• 48B3 CAN Communication with ASC
• 48B5 Injectors Voltage Measurement(control unit internal)
• 48B6 Injectors Voltage Measurement(control unit internal)
• 48B7 Injectors Voltage Measurement(control unit internal)
• 48BC Lambda Sensor Bank 2
• 48C2 CAN Communication with EGS
• 48C5 Injectors Voltage Measurement(control unit internal)
• 48C6 Injectors Voltage Measurement(control unit internal)
• 48C7 Injectors Voltage Measurement(control unit internal)
• 48CA Lambda Sensor Bank 2
• 48CB Lambda Sensor Bank 2
• 48D2 CAN Communication with Instrument Cluster
• 48D3 CAN Communication with Instrument Cluster
• 48DA Control Unit Internal 25
• 48DB Control Unit Internal 25
• 48EA Control Unit Internal 26
• 48EB Control Unit Internal 26
• 48F2 CAN BUS Hardware
• 48F3 CAN BUS Hardware
• 48F7 Injectors Wiring Loom
• 48FD Control Unit Internal 27
• 4900 DSC Torque Intervention
• 4907 Injectors Selector Switch(control unit internal)
• 490B Control Unit Internal 28
• 4912 CAN BUS Hardware Defect in Operation
• 4913 CAN BUS Hardware Fault in Initialisation
• 4917 Injectors Charge Switch(control unit internal)
• 4920 Transmission Link
• 4925 Throttle Valve Actuator 2 Activation
• 492A Lambda Sensor Bank 2 Heater
• 492B Lambda Sensor Bank 2 Heater
• 4936 Throttle Valve Actuator 2 Activation
• 493D Lambda Sensor Bank 2
• 4947 Throttle Valve Actuator 2 Activation
• 4948 Throttle Valve Actuator 2 Activation
• 494D Lambda Sensor Bank 2
• 4957 Throttle Valve Actuator 2
• 495A Exhaust Temp Sensor before DPF Bank 2
• 495B Exhaust Temp Sensor before DPF Bank 2
• 4967 Throttle Valve Actuator 2
• 496A DPF Bank 2
• 497A DPF Bank 2
• 4991 Message : Instrument Cluster
• 4992 Message : Instrument Cluster
• 4997 Throttle Valve Actuator 2
• 49A2 Message : Ambient Temperature
• 49B0 Message : Torque Request
• 49C0 Message : Torque Request
• 49D2 Message : Torque Request
• 49E0 Message : Torque Request
• 49E7 Throttle Actuator
• 49F2 Message : Vehicle Speed
• 49F3 Message : Vehicle Speed
• 4A02 Terminal 15
• 4A03 Terminal 15
• 4A07 Alternator
• 4A08 Alternator
• 4A10 BSD Interface
• 4A13 BSD Interface
• 4A15 Alternator
• 4A17 Alternator
• 4A18 Alternator
• 4A22 Boost Air Pressure Actuator 2 Activation
• 4A23 Boost Air Pressure Actuator 2 Activation
• 4A25 Intelligent Battery Sensor
• 4A27 Intelligent Battery Sensor
• 4A28 Intelligent Battery Sensor
• 4A30 Multifunction Steering Wheel- Toggle Bit
• 4A31 Multifunction Steering Wheel- Frequency Counter
• 4A32 Multifunction Steering Wheel- No Signal
• 4A33 Multifunction Steering Wheel- Signal not Plausible
• 4A35 Intelligent Battery Sensor
• 4A37 Intelligent Battery Sensor
• 4A38 Intelligent Battery Sensor
• 4A41 EWS Interface
• 4A42 EWS Interface
• 4A43 EWS Interface
• 4A45 Intelligent Battery Sensor
• 4A47 Intelligent Battery Sensor
• 4A48 Intelligent Battery Sensor
• 4A50 EWS Code Storage
• 4A51 EWS Code Storage
• 4A56 Power Management Battery
• 4A58 Power Management Battery
• 4A60 EWS Manipulation
• 4A61 EWS Manipulation
• 4A62 EWS Manipulation
• 4A63 EWS Manipulation
• 4A65 Power Management Vehicle Electrical System
• 4A66 Power Management Vehicle Electrical System
• 4A67 Power Management Vehicle Electrical System
• 4A70 Reference Values Incorrect
• 4A80 Intake Air Hose
• 4AA2 CAN Communication with EGS
• 4AA3 CAN Communication with EGS
• 4AB0 Electrical Aux Heater
• 4AD5 Zero Quantity Adaptation Injector 1
• 4AD6 Zero Quantity Adaptation Injector 1
• 4AE0 E-Box Ventilator -Short circuit to B+
• 4AE1 E-Box Ventilator -Short circuit to B-
• 4AE2 E-Box Ventilator -Activation Interrupted
• 4AE3 E-Box Ventilator -Plausibility, Overtemp of Output Stage
• 4AE5 Zero Quantity Adaptation Injector 2
• 4AE6 Zero Quantity Adaptation Injector 2
• 4AF0 Control Unit Temperature Sensor
• 4AF1 Control Unit Temperature Sensor
• 4AF5 Zero Quantity Adaptation Injector 3
• 4AF6 Zero Quantity Adaptation Injector 3
• 4B00 Control Unit Temperature
• 4B05 Zero Quantity Adaptation Injector 4
• 4B06 Zero Quantity Adaptation Injector 4
• 4B10 Smooth Running Regulation -Correction Quantity too High
• 4B11 Smooth Running Regulation -Correction Quantity too Low
• 4B15 Zero Quantity Adaptation Injector 5
• 4B16 Zero Quantity Adaptation Injector 5
• 4B20 Electro ventilator -Blocked
• 4B22 Electro Ventilator
• 4B25 Zero Quantity Adaptation Injector 6
• 4B26 Zero Quantity Adaptation Injector 6
• 4B35 Oil Sensor
• 4B36 Oil Sensor
• 4B37 Oil Sensor
• 4B38 Oil Sensor
• 4B45 Injector Cyl 1 Energy Consumption Measurement
• 4B50 Quantity Compensation
• 4B55 Injector Cyl 2 Energy Consumption Measurement
• 4B60 Quantity Compensation
• 4B65 Injector Cyl 3 Energy Consumption Measurement
• 4B75 Injector Cyl 4 Energy Consumption Measurement
• 4B80 Rail Pressure not Plausible
• 4B85 Injector Cyl 5 Energy Consumption Measurement
• 4B90 Rail Pressure Control at Engine Start
• 4B95 Injector Cyl 6 Energy Consumption Measurement
• 4BA0 Intake Air Temperature Sensor -Signal too High or Short
• 4BA1 Intake Air Temperature Sensor -Signal too Low
• 4BB0 Air Flow Sensor Power Supply
• 4BB1 Air Flow Sensor Power Supply
• 4BB5 Air Flow Meter -Signal too Low
• 4BB6 Air Flow Meter -Signal too High
• 4BC0 Air Flow Meter -Signal too Low
• 4BC1 Air Flow Meter -Signal too High
• 4BC2 Air Flow Meter -Short Circuit
• 4BC5 Intake Air Temperature Sensor
• 4BC6 Intake Air Temperature Sensor
• 4BC7 Intake Air Temperature Sensor
• 4BD2 ARS Torque Request
• 4BD5 Engine Support
• 4BD6 Engine Support
• 4BD7 Engine Support
• 4BD8 Engine Support
• 4BE2 Message : Transmission data
• 4BE7 Message : Transmission data 2
• 4BF2 Message : Air Conditioning
• 4BF7 Message : Range
• 4C00 Message : Cruise Control
• 4C01 Message : Cruise Control
• 4C02 Message : Cruise Control
• 4C06 Message : ARS Status
• 4C07 Message : ARS Status
• 4C12 Message : DSC Status
• 4C15 Message : Terminal 15
• 4C16 Message : Terminal 15
• 4C17 Message : Terminal 15
• 4C20 Message : DSC Torque
• 4C21 Message : DSC Torque
• 4C22 Message : DSC Torque
• 4C23 Message : DSC Torque
• 4C27 Message : Vehicle Speed
• 4C28 Message : Vehicle Speed
• 4C45 Injector Cyl 7 Energy Consumption Measurement
• 4C55 Injector Cyl 8 Energy Consumption Measurement
• 4C65 Zero Quantity Adaptation Injector 7
• 4C66 Zero Quantity Adaptation Injector 7
• 4C75 Supply Voltage Air Mass Flow Sensor 2
• 4C76 Supply Voltage Air Mass Flow Sensor 2
• 4C95 Zero Quantity Adaptation Injector 8
• 4C96 Zero Quantity Adaptation Injector 8
• 4CA2 Message : Power Management
• 4CB2 Message : Power Management
• 4CB3 Message : Power Management
• 4CF3 DPF -Plausibility -Exhaust Gas Pressure
• 4D00 Exhaust Backpressure Sensor Bank 1
• 4D03 Exhaust Backpressure Sensor Bank 1
• 4D25 Exhaust Temp Sensor before Catalytic Converter Bank 2
• 4D26 Exhaust Temp Sensor before Catalytic Converter Bank 2
• 4D45 Exhaust Temp Sensor before DPF Bank 2
• 4D46 Exhaust Temp Sensor before DPF Bank 2
• 4D56 DPF Bank 2
• 4D65 DPF System
• 4D75 DPF System
• 4D81 Boost Pressure Actuator 2 Activation
• 4D98 Exhaust Backpressure Sensor Bank 2
• 4DA3 Boost Pressure Control
• 4DA5 Exhaust Backpressure Sensor Bank 2
• 4DA8 Exhaust Backpressure Sensor Bank 2
• 4DB0 EGR Controller 2 Activation
• 4DC1 EGR Controller 2 Activation
• 4DD2 EGR Controller 2 Activation
• 4DD3 EGR Controller 2 Activation
• 4DD5 Exhaust Temp Sensor before DPF Bank 2
• 4DE0 Monitoring Master/Slave – Private CAN
• 4DE1 Monitoring Master/Slave – Private CAN
• 4DE3 Monitoring Master/Slave – Private CAN
• 4DF0 Message : Transmission Torque
• 4DF1 Message : Transmission Torque
• 4DF2 Message : Transmission Torque
• 4DF3 Message : Transmission Torque
• 4DF5 Exhaust Temp Sensor before DPF Bank 2
• 7073 Automatic Gearbox Switch Signal
• CD87 CAN Bus Communication Error
• CD8B CAN Bus -Control Module has Left the Bus
• 2AF4, P-Code P121F NOx-Sensor linearer Lambdasignalkreis (Bank 1) Kurzschluss - Fehlerart:8 (4474) Kurzschluss
  2AF2, P-Code P122C NOx-Sensor Kurzschluss - Fehlerart:8 (4474) Kurzschluss
  2AF6, P-Code P122F NOx-Sensor binarer Lambdasignalkreis (Bank 1) Kurzschluss - Fehlerart:8 (4474) Kurzschluss
  30E6, P-Code P128E NOx-Sensor binarer Lambdasignalkreis (Bank 1) - Dynamik zu niedrig
  2AF9 (to od czujnika temperatury plynu chlodzacego), P-Code P127A NOx Sensorsignal (Bank 1) Signal zu hoch bei Schubprufung
  2af0 nitrous oxide sensor hearing
  2a99 crankshaft ute let correlation nitrous oxide sensor heating
